Product Overview: Cisco Catalyst C1300-8FP-2G Switch
The switch provides 8 x 10/100/1000BASE-T PoE+ (IEEE 802.3af/at) downlink ports with up to 30 W each, and 2 x Gigabit Ethernet SFP/RJ-45 uplink ports for flexible copper or fibre backbone connectivity. The "FP" mark stands for full PoE. The switch's total PoE budget is 120W, which means it can power IP phones, wireless access points, surveillance cameras and IoT endpoints over one cable, without an additional power supply.
The switch is powered by a 1.4GHz dual-core ARM CPU, 1GB DDR4 DRAM and 512MB flash memory. It has 20Gbps non-blocking switching capacity and 14.88 Mpps wire-speed forwarding rate at 64 byte packet size. The platform supports 16,000 MAC address entries, up to 4,093 VLANs, jumbo frames up to 9,000 bytes and a 1.5MB packet buffer.
The fanless chassis (268 × 297 × 44 mm, 3.05 kg) provides quiet operation, ideal for open-plan offices, classrooms and retail spaces. IEEE 802.3az Energy-Efficient Ethernet slashes power consumption. The switch features an integrated 100-240 VAC power supply with a maximum consumption of 145.44 W for powering PoE devices. Up to eight units can be managed as a single logical entity with a single IP address, simplifying management through front-panel stacking.
Layer 3 supports static IPv4/IPv6 routing and inter-VLAN routing Supports up to 990 IPv4 routes and 128 IPv4 interfaces. Layer 2 features include 802.1Q VLAN tagging, Voice VLAN, Auto Surveillance VLAN (ASV), Link Aggregation Control Protocol (LACP) with up to 8 groups, MSTP (8 instances), RPVST+ (126 instances) and IGMP snooping for up to 2,000 multicast groups. Quality of Service (QoS) provides 8 hardware priority queues with 802.1p and DSCP based classification and WRR/strict scheduling.
Management is easy with Cisco Business Dashboard (web-based GUI), CLI and SNMP, and deployment is easy with zero touch with Cisco Network Plug & Play. Advanced security features include IEEE 802.1X port-based authentication, ACLs with up to 1,024 rules, Dynamic ARP Inspection (DAI), IP Source Guard, DHCP snooping, DoS attack prevention, and IPv6 First Hop Security. The C1300-8FP-2G series is covered by Cisco's Limited Lifetime Hardware Warranty and is the ideal solution for secure office connectivity with full PoE+ (up to 30W per port), unified communications (IP phones/VoIP servers), education classrooms (APs, interactive displays), retail environments (POS, cameras, APs) and branch office access layers that require quiet, fanless operation and enterprise-grade management.
What is the product positioning and architecture?
The Cisco Catalyst C1300-8FP-2G is part of the Catalyst 1300 Series, designed for SMB (Small and Medium Business) access-layer networking and branch deployments.
It is positioned as:
● PoE+ access switch for edge devices.
● Lightweight Layer 3 (Lite L3) switching platform.
● Fiber + copper hybrid uplink switch.
● Simple, secure, and cost-efficient enterprise edge solution.
It runs a Linux-based Catalyst 1300 operating system, not traditional Cisco IOS/IOS-XE.
Port architecture and hardware design
Downlink (Access Ports)
● 8 × 10/100/1000BASE-T RJ45 PoE+ ports.
● Auto-negotiation support (10/100/1000 Mbps).
● Auto MDI/MDIX support.
Uplink (Combo Ports)
● 2 × Gigabit combo uplink ports:
○ RJ45 (copper Ethernet).
○ SFP (fiber module support, 1G).
Combo design allows flexible deployment in copper-only or fiber-backbone environments.
PoE (Power over Ethernet) capability
Standards supported:
● IEEE 802.3af (PoE).
● IEEE 802.3at (PoE+).
Power delivery:
● Up to 30W per port.
● Total PoE budget: ~120W (varies slightly by power configuration).
Power management features:
● Dynamic PoE allocation.
● Per-port power prioritization.
● Overload protection.
● Power budgeting and scheduling control.
Typical device support:
● Wi-Fi access points (Wi-Fi 5 / Wi-Fi 6 low-mid power).
● IP surveillance cameras.
● VoIP phones.
● IoT sensors and controllers.
Layer 2 switching features
VLAN capabilities:
● IEEE 802.1Q VLAN tagging.
● Voice VLAN optimization.
● VLAN trunk/access mode.
● Private VLAN support (basic isolation scenarios).
Spanning Tree Protocols:
● STP / RSTP / MSTP.
● BPDU Guard.
● Loop Guard.
Switching controls:
● Port Security (MAC limiting).
● Storm Control (broadcast/multicast suppression).
● Link Aggregation (LACP).
Layer 3 (Lite L3) capabilities
This model provides basic Layer 3 routing functions, not full enterprise routing.
Routing features:
● Static routing.
● Inter-VLAN routing.
● IPv4 and IPv6 dual-stack support.
Network services:
● DHCP Server / Relay.
● ARP handling.
● Basic routing table management.
Note: Dynamic routing protocols such as OSPF or BGP are not supported.
