AITI Tech Limited is one of the leading manufacturers and suppliers of catalyst c9200-24t in China. With over 20 years' experience, we warmly welcome you to buy bulk cheap catalyst c9200-24t in stock here from our factory. All our products are with high quality and low price. Contact us for pricelist.
Port Configuration & Hardware Specifications
The switch features 24 x 10/100/1000BASE-T data ports (non-PoE) with modular uplink slots supporting C9200-NM series network modules (1G SFP, 10G SFP+, 25G, or 40G uplinks). It delivers a switching capacity of 128 Gbps (288 Gbps in stacked mode) and a forwarding rate of 95.23 million packets per second (Mpps). The MAC address table supports 32,000 entries, VLAN capacity up to 4,096, and jumbo frames up to 9,198 bytes. Onboard memory includes 4 GB DRAM and 4 GB flash storage. The chassis supports dual field-replaceable power supplies (default PWR-C6-125WAC) and redundant fans for high availability.
Stacking & High Availability
StackWise-160 technology enables 160 Gbps stacking bandwidth, allowing up to eight switches to be managed as a single logical unit for simplified operations and enhanced resilience. Stacking also increases total switching capacity to 288 Gbps.
Security & Management
Built on Cisco IOS XE and the UADP 2.0 Mini ASIC, the switch includes hardware-based AES-128 MACsec encryption, 802.1X authentication, DHCP Snooping, Dynamic ARP Inspection, and Encrypted Traffic Analytics (ETA) for visibility into encrypted threats. Management options include CLI, Cisco Catalyst Center, Meraki dashboard, NETCONF, RESTCONF, and SNMP. The switch is SD-Access ready, providing policy-based automation, micro-segmentation, and zero-trust network access.
Software Licensing & Ideal Deployment
Available with two software license tiers: Network Essentials (C9200-24T-E) for foundational Layer 2/3 features, or Network Advantage (C9200-24T-A) for full dynamic routing (OSPF, EIGRP, IS-IS, BGP) and VRF-based segmentation. The C9200-24T series is ideal for server rooms, computer labs, administrative networks, classroom access layers, and branch office data environments where PoE is not required, offering the lowest power consumption in the Catalyst 9200 family with its efficient 125W power supply design.
