AITI Tech Limited is one of the leading manufacturers and suppliers of catalyst c9200-48t in China. With over 20 years' experience, we warmly welcome you to buy bulk cheap catalyst c9200-48t in stock here from our factory. All our products are with high quality and low price. Contact us for pricelist.
Port Configuration & Hardware Specifications
The switch features 48 x 10/100/1000BASE-T data ports (non-PoE) with modular uplink slots supporting C9200-NM series network modules with a choice of 1G SFP, 10G SFP+, or 25G (1/10/25G) uplinks. It delivers a switching capacity of 176 Gbps and a forwarding rate of 261.9 million packets per second (Mpps). The MAC address table supports 32,000 entries, VLAN capacity up to 4,096, jumbo frames up to 9,198 bytes, packet buffer of 6 MB, and supports up to 4,000 IPv4 routes and 2,000 IPv6 routes. Onboard memory includes 4 GB of DRAM and 4 GB of flash storage. The chassis supports dual field-replaceable power supply units (PWR-C6-125WAC or PWR-C5-125WAC) and redundant fans for high availability.
Stacking, Security & Management
StackWise-160 technology provides 160 Gbps stacking bandwidth, allowing up to eight switches to be managed as a single logical unit for simplified operations, resilience, and wire-speed performance with all ports operating at line rate.
Built on Cisco IOS XE and the UADP 2.0 Mini ASIC, the switch includes hardware-based AES-128 MACsec encryption with policy-based segmentation and trustworthy solutions for hardware, software, and data integrity Advanced security features include 802.1X authentication, DHCP Snooping, Dynamic ARP Inspection, Flexible NetFlow up to 16,000 entries, and Encrypted Traffic Analytics. Management options include CLI, Cisco Catalyst Center, NETCONF, RESTCONF, and SNMP, with support for advanced Layer 3 dynamic routing protocols including OSPF, EIGRP, IS-IS, BGP, RIP, and VRF-based segmentation. The switch is SD-Access ready, offering policy-based automation, segmentation, and zero-trust network access.
Software Licensing & Ideal Deployment
Available with two software license tiers: Network Essentials (C9200-48T-E) for foundational Layer 2/3 features, static routing, and simplified network segmentation; and Network Advantage (C9200-48T-A) for full dynamic routing (OSPF, EIGRP, IS-IS, BGP), VRF-based multi-tenancy, and advanced policy capabilities. The C9200-48T series is ideal for server rooms, computer labs, administrative networks, data center top-of-rack connectivity, and classroom access layers where PoE is not required, offering the lowest power consumption in the Catalyst 9200 data-only family.
