AITI Tech Limited is one of the leading manufacturers and suppliers of catalyst c9200cx-12p-2x2g in China. With over 20 years' experience, we warmly welcome you to buy bulk cheap catalyst c9200cx-12p-2x2g in stock here from our factory. All our products are with high quality and low price. Contact us for pricelist.
Port Configuration & PoE+ Support
The switch includes 12 x 10/100/1000BASE-T downlink ports with PoE+ (IEEE 802.3at) support, delivering up to 30W per port to power IP phones, wireless access points, surveillance cameras and IoT endpoints.It adds two additional 1000BASE-T ports and two permanent 10G SFP+ uplinks for high-speed backbone and network aggregation.PoE is limited to 240W total that you can allocate freely to use with the devices you hook up.
Power options stacking and performance
The switch offers 68 Gbps switching capacity and 50.59 Mpps forwarding rate for wire speed non blocking performance.StackWise 80 technology offers 80 Gbps stacking capacity (up to 160 Gbps across the series) to enable up to eight switches to be operated as a single logical unit, making it easier to manage and reducing downtime during maintenance.The C9200CX-12P-2X2G is powered by a single internal 315W AC power supply and provides flexible power options upstream such as IEEE 802.3bt Class 6 PoE input and low or high-voltage DC adapters.
Best Management and Deployment Security
Built on Cisco IOS XE and the UADP 2.0 Mini ASIC, it delivers strong security features such as hardware accelerated AES-256 MACsec encryption, 802.1X authentication, DHCP Snooping and Dynamic ARP Inspection to safeguard the integrity of hardware, software and data.You can manage it via CLI, RESTCONF, NETCONF, SNMP, or Cisco Catalyst Center.The switch supports full Layer 3 dynamic routing protocols such as OSPF, EIGRP, BGP and IS-IS, as well as rich QoS capabilities for optimising voice, video and data traffic.
The switch is offered in two software license options, Network Essentials (-E) for basic Layer 2/3 feature set and static routing, and Network Advantage (-A) for full dynamic routing and VRF-based segmentation. The C9200CX-12P-2X2G Series is ideal for small and medium branch offices, retail POS, hotel networks and IoT edge deployments that require silent operation, low power consumption and integrated PoE+ delivery in a small footprint.
FAQ
Q1: What is Cisco Catalyst C9200CX-12P-2X2G for?
A1: Cisco Catalyst C9200CX-12P-2X2G is optimised for space- and noise-constrained enterprise deployments like small branch offices, retail stores, hotels, and IoT edge.
Q2: Is this switch PoE+ capable and what is the power budget?
A2: Yup. It includes: ● 12 x PoE+ (IEEE 802.3at) ports.
● Up to 30W per port Approx.
● 240W total PoE power budget.
This enables powering of IP phones, APs, cameras and IoT devices.
Q3: What uplink options does it provide?
A3: The switch consists of: ● 2 x 1G RJ-45 uplink ports.
● 2 x 10G SFP+ uplink ports.
They are used for high-speed aggregation and backbone connectivity.
Q4: Is this designed for noisy environments?
A4: Yeah. Silent, fanless operation makes it perfect for: ● Office space.
● rooms / hallways in hotels.
● Cash register areas in retail stores.
● Clinics and classroom.
Q5: Switching performance?
A5: It provides: ●~68 Gbps switching capacity.
● ~50.59 Mpps forwarding rate.
This allows non-blocking wire-speed performance for typical enterprise edge deployments.
Q6: Can you stack it?
A6: Yes. StackWise technology support: ● Stack bandwidth up to 80 Gbps.
● Up to 8 switches in stack.
This makes management easier and redundancy improved.
Q7: What routing features are supported?
A7: It supports Layer 3 features such as: ● Static routing (default).
● OSPF.
● EIGRP.
● BGP IS-IS (License dependent).
Q8: What security features do you have?
A8: Built-in Key security includes: Port Authentication (802.1X) -DHCP Snooping: ● Dynamic ARP Inspection-MACsec (AES-256 hardware encryption).
