AITI Tech Limited is one of the leading manufacturers and suppliers of catalyst c9200l-24t-4x in China. With over 20 years' experience, we warmly welcome you to buy bulk cheap catalyst c9200l-24t-4x in stock here from our factory. All our products are with high quality and low price. Contact us for pricelist.
Port Configuration & Hardware Specifications
The switch features 24 x 10/100/1000BASE-T data ports (non-PoE) plus 4 fixed 10G SFP+ uplinks, delivering a switching capacity of 128 Gbps and a forwarding rate of 95.23 million packets per second (Mpps). The MAC address table supports 16,000 entries, VLAN capacity is up to 1024, and jumbo frame support reaches 9,198 bytes. Onboard memory includes 2 GB DRAM and 4 GB flash, with an MTBF of approximately 526,000 hours.
Security & High Availability
Built on Cisco IOS XE, the switch includes hardware-based AES-128 MACsec encryption, 802.1X authentication, DHCP Snooping, and Dynamic ARP Inspection for robust network security. StackWise-80 technology enables 80 Gbps stacking bandwidth, allowing up to eight switches to operate as a single logical unit. Dual hot-swappable power supply slots support redundancy for continuous operation.
Software & Licensing
The switch is available with two software license tiers: Network Essentials (C9200L-24T-4X-E) or Network Advantage (C9200L-24T-4X-A). Network Essentials supports basic Layer 2 switching and static routing, while Network Advantage unlocks full dynamic routing (OSPF, EIGRP, BGP, ISIS) and VRF/VXLAN segmentation. Cisco DNA licenses are also required.
Ideal Deployment
The C9200L-24T-4X series is ideal for campus access layers, data aggregation at branch offices, and networks requiring high-speed 10G uplinks without Power over Ethernet.
