AITI Tech Limited is one of the leading manufacturers and suppliers of catalyst c1200-8t-e-2g in China. With over 20 years' experience, we warmly welcome you to buy bulk cheap catalyst c1200-8t-e-2g in stock here from our factory. All our products are with high quality and low price. Contact us for pricelist.
Port Configuration & Performance
The switch is equipped with 8 × Gigabit Ethernet (10/100/1000) RJ-45 downlink ports plus 2 × combo Gigabit SFP/RJ-45 uplink ports, allowing flexible fiber or copper backbone integration. Designed as a data-only model with zero PoE output, it provides a total switching capacity of 20 Gbps and a forwarding rate of 14.88 million packets per second (Mpps). Key resources include an 8,000-entry MAC address table, 255 active VLANs, 32 static IPv4 routes, and 9,000-byte jumbo frame support.
Security & Management Capabilities
Built on a Linux-based operating system, the C1200-8T-E-2G includes advanced security features such as IEEE 802.1X port security, Access Control Lists (ACLs), and Denial-of-Service (DoS) attack prevention. Management is simplified through multiple interfaces: an intuitive Cisco Business mobile app, web-based GUI, Cisco Business Dashboard, and full Command-Line Interface (CLI) access with support for SSH, SNMP, and HTTPS. The platform uses a 1.4 GHz dual-core ARM processor with 1 GB DDR4 DRAM and 512 MB flash memory.
Operational Features & Ideal Use Cases
The device complies with IEEE 802.3az Energy-Efficient Ethernet (EEE) to optimise power consumption, drawing a maximum of 10.65W with an external AC adapter. Its fanless design ensures silent operation in noise-sensitive environments such as open-plan offices, classrooms, medical clinics, and hospitality venues. The 1RU rack-mountable chassis measures 268 × 185 × 44 mm (W×D×H) and weighs 1.39 kg, supporting both desktop and standard 19-inch rack mounting. Additional administrative features include a USB-C console port for local management, port mirroring, STP/RSTP/MSTP loop prevention, LACP link aggregation, and QoS prioritisation with eight hardware queues . The switch is backed by Cisco's Limited Lifetime Hardware Warranty plus one year of free technical support, with no mandatory subscription fees.
Well suited for SMB main offices, remote site connectivity, education and training facilities, and retail or hospitality networks requiring secure, energy-efficient switching with flexible uplink options and silent operation.
Hot Tags: catalyst c1200-8t-e-2g, China catalyst c1200-8t-e-2g suppliers
